System Specifications
| Panel size/resolution | 10.1” / 1024 x 600 |
|---|---|
| System memory (standard/max) | 8,192 MB |
| System hard drive | 256 GB SSD (standard) |
| Interface | 10/100/1,000-Base-T Ethernet; USB 2.0; Wi-Fi 802.11 b/g/n (optional) |
| Network protocols | TCP/IP (IPv4/IPv6); SMB; LPD; IPP; SNMP; HTTP(S); AppleTalk; Bonjour |
| Automatic Document Feeder | Up to 100 originals; A6-A3; 35-163 g/m²; RADF or Dualscan ADF available |
| Paper input capacity (standard/max) | 1,150 sheets / 6,650 sheets |
| Paper tray input (standard) | 1x 500 sheets; A6-A3; custom sizes; 52-256 g/m² 1x 500 sheets; A5-SRA3; custom sizes; 52-256 g/m² |
| Paper tray input (optional) | 1x 500 sheets; A5-A3; 52-256 g/m² 2x 500 sheets; A5-A3; 52-256 g/m² 1x 2,500 sheets; A4; 52-256 g/m² |
| Large capacity tray (optional) | 1x 3,000 sheets; A4; 52-256 g/m² |
| Manual bypass | 150 sheets; A6-SRA3; Custom sizes; Banner; 60-300 g/m² |
| Automatic duplexing | A5-SRA3; 52-256 g/m² |
| Finishing modes | Offset; Group; Sort; Staple; Punch; Half-fold; Letter-fold; Booklet |
| Output capacity (standard) | Max. 250 sheets |
| Output capacity (optional) | Max. 3,300 sheets |
| Stapling | Max. 50 sheets or 48 sheets + 2 cover sheets (up to 209 g/m²) |
| Letter fold | Max. 3 sheets |
| Letter fold capacity | Max. 30 sheets; unlimited (without tray) |
| Booklet | Max. 20 sheets or 19 sheets + 1 cover sheet (up to 209 g/m²) |
| Booklet output capacity | Max. 100 booklets; unlimited (without tray) |
| Copy/print volume (monthly) | Rec. 16,000 pages; Max.¹ 130,000 pages ¹If the maximum volume is reached within a period of one year, then a maintenance cycle must be performed |
| Toner lifetime | Black up to 28,000 pages CMY up to 28,000 pages |
| Imaging unit lifetime | Black up to 170,000/1,000,000 pages (drum/developer) CMY up to 65,000/1,000,000 pages (drum/developer) |
| Power consumption | 220-240 V / 50/60 Hz; Less than 1.58 kW |
| System dimension (WxDxH) | 615 x 688 x 779 mm (without options) |
| System weight | Approx. 84.0 kg (without options) |
Printer Specifications
| Print resolution | 1,800 (equivalent) x 600 dpi; 1200 x 1200 dpi |
|---|---|
| Page description language | PCL 6 (XL3.0); PCL 5c; PostScript 3 (CPSI 3016); XPS |
| Operating systems | Windows 7 (32/64); Windows 8/8.1 (32/64); Windows 10 (32/64); Windows Server 2008 (32/64); Windows Server 2008 R2; Windows Server 2012; Windows Server 2012 R2; Windows Server 2016; Windows Server 2019; Macintosh OS X 10.10 or later; Unix; Linux; Citrix |
| Printer fonts | 80 PCL Latin; 137 PostScript 3 Emulation Latin |
| Mobile printing | AirPrint (iOS); Mopria (Android); ineoPRINT |
Printer Specifications (optional)
| Print controller | Embedded Fiery IC-420 |
|---|---|
| Controller CPU | AMD GX-424CC @ 2.4 GHz |
| Memory/HDD | 4,096 MB / 500 GB |
| Page description language | Adobe PostScript 3 (CPSI 3020); PCL 6; PCL 5c |
| Operating systems | Windows 7 (32/64); Windows 8 (32/64); Windows 10 (32/64); Windows Server 2008 (32/64); Windows Server 2008 R2; Windows Server 2012; Windows Server 2012 R2; Windows Server 2016; Windows Server 2019; Macintosh OS X 10.10 or later; Linux |
Scanner Specifications
| Scan speed (mono/colour) | Up to 100/100 ipm in simplex Up to 200/200 ipm in duplex |
|---|---|
| Scan modes | Scan-to-eMail (Scan-to-Me); Scan-to-SMB (Scan-to-Home); Scan-to-FTP; Scan-to-Box; Scan-to-USB; Scan-to-WebDAV; Scan-to-URL; TWAIN scan |
| File formats | JPEG; TIFF; PDF; Compact PDF; Encrypted PDF; XPS; Compact XPS; PPTX Optional: Searchable PDF; PDF/A 1a and 1b; Searchable DOCX/PPTX/XLSX |
| Scan destinations | 2,100 (single + group); LDAP support |
Copier Specifications
| Imaging technology | Laser |
|---|---|
| Toner technology | HD polymerised toner |
| Copy/print speed A4 (mono/colour) | Up to 25/25 ppm |
| Copy/print speed A3 (mono/colour) | Up to 15/15 ppm |
| Autoduplex speed A4 (mono/colour) | Up to 25/25 ppm |
| 1st copy out time A4 (mono/colour) | 5.2/6.9 sec. |
| Warm-up time | Approx. 11 sec. in mono; 13 sec. in color² ² Warm-up time may vary depending on the operating environment and usage |
| Copy resolution | 600 x 600 dpi |
| Gradation | 256 gradations |
| Multicopy | 1-9,999 |
| Original format | A6-A3; Custom sizes |
| Magnification | 25-400% in 0.1% steps; Auto-zooming |
Fax Specifications
| Fax standard | Super G3 (optional) |
|---|---|
| Fax transmission | Analogue; i-Fax; Colour i-Fax; IP-Fax |
| Fax resolution | Up to 600 x 600 dpi |
| Fax compression | MH; MR; MMR; JBIG |
| Fax modem | Up to 33.6 Kbps |
| Fax destinations | 2,100 (single + group) |
User Box Specifications
| Storable documents | Up to 3,000 documents or 10,000 pages |
|---|---|
| Type of user boxes | Public; Personal (with password or authentication); Group (with authentication) |
| Type of system boxes | Secure print; Encrypted PDF print; Fax receipt; Fax polling |
System Features
| Security | Standard: ISO 15408 HCD-PP Common Criteria (in evalutation); IP filtering and port blocking; SSL2; SSL3 and TLS1.0/1.1/1.2 network communication; IPsec support; IEEE 802.1x support; User authentication; Authentication log; Secure print; Kerberos; Hard disk overwrite; Hard disk data encryption (AES 256); Confidential fax receipt; Print user data encryption Optional: Antivirus realtime scanning (Bitdefender®); Copy protection (Copy Guard, Password Copy) |
|---|---|
| Accounting | Standard: Up to 1,000 user accounts; Active Directory support (user name + password + e-mail + smb folder); User function access definition Optional: Biometric authentication (finger vein scanner); ID card authentication (ID card reader); Authentication by mobile device (Android/iOS) |
| Software | store+find (opt.); convert+share (opt.); Device Manager; Box Operator; Data Administrator (user accounts |
- Vse specifikacije se nanašajo na papir velikosti A4, kakovost 80 gsm.
- Podpora in razpoložljivost naštetih specifikacij in funkcionalnosti sta odvisni od operacijskih sistemov, aplikacij in omrežnih protokolov, kot tudi konfiguracije omrežja in sistema.
- Pričakovana življenjska doba potrošnega materiala temelji na posebnih delovnih pogojev, kot so pokritost strani za določeno velikost strani (5% pokritost A4). Dejanska življenska doba vsakega potrošnega materiala se razlikujejo glede na uporabo in druge spremenljivke tiskanja vključno s pokritostjo strani, velikostjo strani, vrste medijev, razliko med stalno ali občasno tiskanje, temperature in vlažnosti okolja .
- Nekatere ilustracije izdelkov vsebujejo dodatke.
- Specifikacije in dodatki temeljijo na informacijah, ki so na voljo v času tiska in se lahko spremenijo brez obvestil.
- Sanelec d.o.o. ne jamči za točnost tehničnih podatkov.
- Vse znamke in imena izdelkov so lahko blagovne znamke ali blagovne znamke njihovih lastnikov in so s tem potrjene.
